Von Roll/John C Dolph Dolphon® CR-1035-B Epoxy Casting Resin Kit
- MFR #:Dolphon® CR-1035-B
- EIS #:PH21-Dolphon CR-1035-B
- MFR #:Dolphon® CR-1035-B
- EIS #:PH21-Dolphon CR-1035-B
Von Roll/John C Dolph Dolphon® CR-1035-B Epoxy Casting Resin Kit, Epoxy Base Type, 410 V/Mil Dielectric Strength, 75 Shore D Hardness, 8500 psi Tensile Strength, 6 x 10^4 Cal/sec/cm^2/°C/cm Thermal Conductivity. - CR-1035 is a semi-rigid, two-part, room temperature curing epoxy resin specifically formulated for encapsulation.
$49.23
Select from the options below
Von Roll/John C Dolph Dolphon® CR-1035-B Epoxy Casting Resin Kit, Epoxy Base Type, 410 V/Mil Dielectric Strength, 75 Shore D Hardness, 8500 psi Tensile Strength, 6 x 10^4 Cal/sec/cm^2/°C/cm Thermal Conductivity. - CR-1035 is a semi-rigid, two-part, room temperature curing epoxy resin specifically formulated for encapsulation.
Product Options
Showing 1 out of 1 options
 | Container Size: 8 lb | EIS Part #: DOLCR1035B8LB | $ / Can |
- Attributes
- Features
- Applications
Attributes
General Information
Item NameEpoxy Casting Resin Kit
Trade NameDolphon®
SeriesDolphon® CR-1035-B
Design & Construction
Base TypeEpoxy
Performance Details
Tensile Strength8500 psi
Electrical Properties
Dielectric Strength410 V/mil
Physical Properties
Hardness75 Shore D
Features
- Supplied in kit form for easy measuring of resin and reactor
- Excellent electrical and physical properties
- Good thermal conductivity
- Cures quickly at room temperature
- Low Viscosity for good penetration
- Good machinability of cured resin
- 0.3% (ASTM D-570-59aT) water absorption
- 5.0 x 10^12 ohms surface resistivity
- 6.0 x 10^13 Ohm-cm volume resistivity
- Excellent chemical resistance (most solvents, acids and bases)
- Thermal Conductivity: 6 x 10^4 Cal/sec/cm^2/°C/cm
Applications
- Stators
- Solenoid Coils
- Control Coils
- Electric Motors
- Electrical and Electronic Parts
