Nachi 51208BNLS - 51200 Series Thrust Ball Bearing, MFR ID NAC-51208
- MFR #51208
- EIS #5120802
- UPC #4991893596236
- Midpoint #NAC-51208
$45.86 / Piece
Available to Order
Min QTY1QTY Increment1
more info
Products You May Also Like
Thrust Ball Bearings are made as single-direction and double-direction bearings. Single-direction Thrust Ball Bearings can sustain an axial load in only one direction, whereas Double-direction Thrust Ball Bearings can sustain bi-directional thrust load. Both types of Thrust Ball Bearings cannot sustain a radial load.
Features
- Standard steel cage
General Information
| Item Name | Thrust Ball Bearing |
General Features
| Net Weight | 0.6 lb |
Design & Construction
| Cage Material | JIS SPCC Steel |
| Inner Ring Material | JIS SUJ2 Steel |
| Outer Ring Material | JIS SUJ2 Steel |
| Rolling Element Material | JIS SUJ2 Steel |
Performance Details
| Dynamic Load Capacity | 47000 N |
| Operating Temperature | 120 °C (248 °F) |
| Precision Class | P0 |
| Speed Rating | 2700 rpm (Grease) | 4100 rpm (Oil) |
| Static Load Capacity | 98500 N |
Physical Properties
| Bore Diameter | 40 mm |
| Outside Diameter | 68 mm |
| Overall Width | 19 mm |
| Radial Internal Clearance | CN/C0 |
