3M 9629B Double-Coated Polyester Tape, 1" x 60 yd x 4 Mil, Black/Natural Liner, 36/Case, MFR ID 70006706405
- EIS #3M9629BX1
- UPC #00051111920039
Requires Quote / Roll
Available to Order
Min QTY1QTY Increment1
more info
Pack36/Case
Products You May Also Like
3M 9629B black bonding tape comes in acrylic adhesive. 3M quick bonding adhesive 360 provides high bond strength and has excellent quick stick properties Up to 350 °F short-term heat resistance, Excellent solvent resistance, super quick stick and high adhesion from a thin tape. The variances in thickness often make an important difference in proper performance. - This bonding tape has a 4 Mil thick. Products in this category feature a liner on the back which you peel away from to expose the adhesive material before applying to the substrate. The liner material for this product is composed of glassine paper.
Features
- Excellent adhesion to difficult to bond to surfaces such as HDPE, LDPE and PP, super quick stick
- Higher adhesion from a thinner tape
- High temperature performance
- This tape has a film carrier which can add dimensional stability to foams and other substrates and also makes it easier to handle the tape during slitting and die-cutting
- Adhesive thickness of 1.75 Mil (Back-Side), 1.75 Mil (Face-Side)
- For adhesive strength see TDS
- Temperature rating of -40 to 350 °F
Applications
- For Foam to Powder Coated Painted Surfaces, Low Surface Energy Plastic Adhesion
General Information
| Item Name | Tape |
| Series | 9629B |
General Features
| Type | Double-Coated |
| Shelf Life | 24 Months |
| Storage Temperature | 21 °C |
Design & Construction
| Adhesive Type | Acrylic |
| Carrier Material | Polyester |
| Color | Black/Natural Liner |
| Liner Material | Glassine Paper |
Performance Details
| Shear Strength | See TDS |
Physical Properties
| Adhesive Thickness | 1.75 mil |
| Carrier Thickness | 0.5 mil |
| Core Size | 3 Inch |
| Width | 1 Inch |
| Length | 60 Yard |
| Liner Thickness | 3.2 mil |
| Thickness | 4 Mil |
Environmental Condition
| Resists | Solvent, Humidity, UV, Water, Temperature, Chemical |
| Temperature Rating | 350 °F |
