3M 9019 Double-Coated Polyester Tape, 3-3/8" x 360 yd x 1.1 Mil, Natural/White Liner, MFR ID 9019X3.375
- MFR #70000093412
- EIS #3M9019X3.375
Requires Quote / Roll
Available to Order
Min QTY1QTY Increment1
more info
Products You May Also Like
3M double coated tapes with 3M adhesive 300 feature a thin polyester film for dimensional stability and improved handling with ease of die-cutting and laminating. The high tack adhesive provides relatively high initial adhesion and good shear holding power to a variety of surfaces. - The carrier also provides easier handling during slitting and die-cutting. Polycoated kraft liner that provides moisture stability for large part converting good peel strength and temperature and UV resistance.
Features
- 1.1 Mil double coated tape with a PET polyester carrier on a 55 lb densified kraft paper liner DK
- General industrial applications, electronics, gasket and foam fabricators
- Adhering, joining, affixing, bonding, mounting, holding and attaching dissimilar materials, plastic film lamination bonding, splicing and foam laminating, gasket attachment, hand-held devices and laptops
- For adhesive strength see TDS
- Temperature rating of -40 to 250 °F
Applications
- For Medical/Non-Medical Diagnostic Test Strips, Plastic Film lamination/Bonding, Splicing, Foam lamination, Cell Phone lens Attachment, Gasket Attachment in Hand Held Devices and Laptops
General Information
| Item Name | Tape |
| Series | 9019 |
General Features
| Type | Double-Coated |
| Shelf Life | 24 Months |
| Storage Temperature | 21 °C |
Design & Construction
| Adhesive Type | Acrylic |
| Applicable Material | Flexible Foam, Metal, Foam, HSE Plastics and Glass |
| Carrier Material | Polyester |
| Color | Natural/White Liner |
| Liner Material | Densified Kraft Paper |
Physical Properties
| Adhesive Thickness | 0.3 mil |
| Carrier Thickness | 0.5 mil |
| Core Size | 3 Inch |
| Width | 3.375 Inch |
| Length | 360 Yard |
| Liner Thickness | 3 mil |
| Thickness | 1.1 mil |
Environmental Condition
| Resists | Relative Solvent, UV |
| Temperature Rating | 250 °F |
Supporting Information
| Applicable Materials | Flexible Foam, Metal, Foam, HSE Plastics and Glass |
Documents
No Documents Found
