MFR #:Nu-Sleeve™ SG-200-C
EIS #:PH21-Nu-Sleeve SG-200-C
Series #:Nu-Sleeve™ SG-200-C
MFR #:Nu-Sleeve™ SG-200-C
EIS #:PH21-Nu-Sleeve SG-200-C
Series #:Nu-Sleeve™ SG-200-C
Nu-Sleeve SG-200 is a braided fiberglass sleeve coated with a liquid silicone rubber. The braid is heat treated to optimize coating adhesion and minimize surface irregularities. - Nu-Sleeve SG-200 is available in 5 electrical grades (A, B, C-1 , C-2 and C-3) . It is highly resistant to end-fray and coating fractures and is a non-flammable sleeve.
$0.19
- $802.64
Select from the options below
Nu-Sleeve SG-200 is a braided fiberglass sleeve coated with a liquid silicone rubber. The braid is heat treated to optimize coating adhesion and minimize surface irregularities. - Nu-Sleeve SG-200 is available in 5 electrical grades (A, B, C-1 , C-2 and C-3) . It is highly resistant to end-fray and coating fractures and is a non-flammable sleeve.
Product Options
Showing 8 out of 24 options
Length: 500 ft | Gauge: 20 AWG | Color: Natural | EIS Part #: SRC20NHJ | $ / Foot | ||
Length: 1000 ft | Gauge: 18 AWG | Color: Natural | EIS Part #: SRC18NJJ | $ / Foot | ||
Length: 500 ft | Gauge: 18 AWG | Color: Natural | EIS Part #: SRC18NHJ | $ / Foot | ||
Length: 1000 ft | Gauge: 18 AWG | Color: Black | EIS Part #: SRC18BJJ | $ / Foot | ||
Length: 1000 ft | Gauge: 14 AWG | Color: Natural | EIS Part #: SRC14NJJ | $ / Foot | ||
Length: 500 ft | Gauge: 14 AWG | Color: Natural | EIS Part #: SRC14NHJ | $ / Foot | ||
Length: 500 ft | Gauge: 13 AWG | Color: White | EIS Part #: SRC13WHJ | $ / Foot | ||
Length: 1000 ft | Gauge: 12 AWG | Color: Natural | EIS Part #: SRC12NJJ | $ / Foot |
- Attributes
- Features
- Applications
- Documents
Attributes
General Information
Item NameSilicone Rubber Coated Sleeving
Trade NameNu-Sleeve™ SG-200
SeriesNu-Sleeve™ SG-200-C
Design & Construction
GradeC
Insulation MaterialSilicone Rubber
Braid TypeFiberglass
Insulation TypeClass H
Insulation Coating TypeSilicone
NEMA SpecificationNEMA TF-1 Type 5
Performance Details
Tensile Strength8.3 Mpa
Heat Aging136 hr
Electrical Properties
Dielectric Strength8000 V
Physical Properties
Elongation420%
Hardness37 Shore A
Features
- Nu-Sleeve SG-200 is the ideal choice for high stress applications over a wide temperature range from -55 °C (-67 °F) up to 200 °C (392 °F)
- It is used extensively in high-temperature applications where one or more of the following features are required: flexibility, expandability, abrasion resistance, cut through resistance and chemical resistance
- Self-extinguishing with removal of flame source rate of burning
- Dielectric Grade: C
- Dielectric Strength: Dry: 8000 Volt, 60 Hz AC at 500 V/s Rate of Rise, Wet: >80% of the Dry Values
- Temperature Rating: -55 to 200 °C
Applications
- Coil and Winding Industry (Coils, Motors, Generators, Transformers)
- Lighting Fixtures
- Transportation (Mass Transit, Rail Cars, Locomotives)
- Recreational Vehicles
- Pleasure Boats and Commercial Marine
- Industrial Equipment (Tow Motors, Overhead Cranes, Aerial Platforms)
