Dow Corning brand silicone encapsulants are supplied as two-part liquid component kits with a mix ratio of 1:1. When liquid components are thoroughly mixed, the mixture cures to a flexible elastomer, which is well suited for the protection of electrical/electronic applications. Dow Corning silicone encapsulants cure without exotherm at a constant rate regardless of sectional thickness or degree of confinement. - Dow Corning silicone encapsulant requires no post cure and can be placed in service immediately following the completion of the cure schedule. Standard silicone encapsulants require a surface treatment with a primer in addition to good cleaning for adhesion while primerless silicone encapsulants require only good cleaning.
Features
- Good flowability
- Room temperature or heat accelerated cure
- Moderate thermal conductivity
- Rapid, versatile cure processing controlled by temperature
- Can be considered for uses requiring added flame resistance
- Solventless, thermosetting
- Oxidation, ozone, thermal, UV and water resistance
Applications
- For General Potting Applications, Power Supplies, Connectors, Sensors, Industrial Controls, Transformers, Amplifiers, High Voltage Resistor Packs, Relays
General Information
| Item Name | Silicone Sealant |
| Trade Name | Sylgard® |
| Series | 160 |
General Features
| Shelf Life | 540 Days |
| Standards | WEEE/RoHS Compliant |
Design & Construction
| Cure Type | Room Temperature/Heat Cure |
| Form | Liquid |
Chemical Properties
| Composition | Silicone Elastomer |
Physical Properties
| Container Type | Pail |
| Hardness | 56 Shore A |
| Odor/Scent | Low |
