Dow Corning brand one-part moisture cure adhesives are generally cured at room temperature and in an environment of 30 - 80% relative humidity eliminating the need for curing ovens and the associated costs of energy and capital. Greater than 90% of full physical properties should be attained within 24 - 72 hr and varies according to product. - Faster manufacturing throughput can be achieved since the adhesive and component can be handled in much shorter times of about 10 - 120 min, depending on the adhesive selected and the amount applied.
Features
- Fast tack free room temperature cure
- Flowable
- Controlled silicone volatility
- Cures to soft, low stress elastomer
- No added solvents
- No mixing required
- Room temperature cure, no ovens required
- Faster in-line processing at room temperature with option for heat acceleration
- Able to flow, fill or self-leveling after dispensing
- Reduced potential for silicone volatiles
Applications
- For Sealing of Electronic Equipment and Modules, Parts Fixing on Circuit Board
General Information
| Item Name | Silicone Conformal Coating |
| Series | SE9186 |
General Features
| Type | One-Part |
| Standards | WEEE/RoHS Compliant |
| Storage Temperature | 32 °C |
Design & Construction
| Color | Translucent White |
| Cure Type | Room Temperature |
| Form | Liquid |
Performance Details
| Application Time | 8 min |
| Full Cure Time | 24 - 72 hr |
| Tensile Strength | 360 psi |
Chemical Properties
| Composition | Polydimethyl Siloxane |
| Specific Gravity | 1.03 |
| Viscosity | 6400 cP |
Electrical Properties
| Dielectric Strength | 575V/Mil |
| UL Rating | UL94 V-1 |
Physical Properties
| Container Size | 75mL |
| Container Type | Bottle |
| Elongation | 550% |
| Hardness | 20 Shore A |
| Odor/Scent | Alcohol |
Environmental Condition
| Temperature Rating | -45 to 200 °C |
