Rea Magnet Wire Pyre-ML SDG Heavy Build Round Magnet Wire, MFR ID RHML SDGPC121
- MFR #RHML SDGPC121
- EIS #PH15-RHML SDGPC121
- Series #RHML SDGPC121
$1,949.43 - $3,418.20
Refine your product below or compare all choices in the
Min QTY1QTY Increment1
more info
Pack--Products You May Also Like
| Stock Status | |||
|---|---|---|---|
 | 14 AWG | $ / US pound Pack: 11.75" Reel (121) more info | |
 | 15 AWG | $ / US pound Pack: 11.75" Reel (121) more info | |
 | 16 AWG | $ / US pound Pack: 11.75" Reel (121) more info | |
| 17 AWG | $ / US pound Pack: 11.75" Reel (121) more info | |
| 18 AWG | $ / US pound Pack: 11.75" Reel (121) more info |
Dacron glass is a served filament that is applied over the magnet wire conductor. Capable of continuous operation at 240 °C, ML is designed to withstand extremely harsh environments. ML exhibits the highest thermal capabilities and chemical stability of any available organic film insulated magnet wire. - Dacron glass is a combination of glass and polyester fibers. Rea ML is a film insulation composed of aromatic polyimide resin. Machine windable.
Features
- Polyester fiber/glass fiber combination provides freedom from fraying and superior adhesion
- Outstanding toughness
- Daglas-film constructions provide improved electrical properties
Applications
- For a Wide Variety of Difficult Winding and High Reliability Applications
General Information
| Item Name | Magnet Wire |
| Trade Name | Pyre-ML |
| Series | RHML SDGPC121 |
General Features
| Type | Heavy Build |
| Standards | IEC 60317-60 |
Design & Construction
| Color | Natural |
| Insulation Material | Aromatic Polyimide/Dacron/Fiberglass/Epoxy |
| Shape | Round |
| Material | Copper |
| NEMA Rating | MW 46-C |
Physical Properties
| Reel Diameter | 6.53 Inch |
| Reel Hub Diameter | 1.536 Inch |
| Reel Weight | 79 lb |
| Reel Width | 7 Inch |
Documents
No Documents Found
