CHR CW01-7 polyester films have excellent dimensional stability, high tensile, tear and impact strengths and ultimate elongation up to 120% of its original dimensions. These films exhibit low water absorption and good resistance to oils, greases, strong acids and organic solvents. - Superior tensile strength and adhesion with a high dielectric breakdown voltage. Excellent heat resistance up to 155 °C. They also retain electrical properties, dielectric strength and dielectric constant in continuous operating temperatures from -100 to 350 °F.
Features
- Temperature rating of -20 to 155 °C
Applications
- For Heavy Duty Air and Oil Filled Transformer Applications, Reinforcements, Holding/Separating and Ground Insulation and Heaving Banding and Holding Applications in Larger Coil Winding Processes used to make Transformers, Motors and Generators
General Information
| Item Name | Filament Tape |
| Series | CW01-7 |
Design & Construction
| Adhesive Type | Acrylic |
| Backing Material | Polyester/Glass Filament |
| Color | Natural |
Performance Details
| Adhesive Strength | 50 oz/Inch |
| Breaking Strength | 250 lb/Inch |
| Tensile Strength | 275 lb/Inch |
Electrical Properties
| Dielectric Strength | 6500 V |
Physical Properties
| Elongation | 20% |
| Width | 0.5 Inch |
| Length | 60 Yard |
| Thickness | 0.0073 Inch |
Environmental Condition
| Temperature Rating | 155 °C |
