3M Super 10 Epoxy Electrical Tape
- MFR #:Super 10
- EIS #:PH22-Super 10
- MFR #:Super 10
- EIS #:PH22-Super 10
3M epoxy film electrical tape Super 10 is a 5 Mil total thickness, high dielectric, flame retardant tape. This tape has a thermosetting rubber resin pressure sensitive adhesive that is resistant to heat, oxidation, solvent and oils. The tape is puncture resistant and has excellent electrical and handling properties. The tape offers flexibility, high dielectric strength and conformability for easy handling and application. - In application, the tape maintains good electrical properties after elongation. Tape Super 10 is tough, conformable and resistant to solder damage. Its thermosetting rubber resin pressure sensitive adhesive has good initial adhesion and electrical purity.
$0.02
- $679.16
Select from the options below
3M epoxy film electrical tape Super 10 is a 5 Mil total thickness, high dielectric, flame retardant tape. This tape has a thermosetting rubber resin pressure sensitive adhesive that is resistant to heat, oxidation, solvent and oils. The tape is puncture resistant and has excellent electrical and handling properties. The tape offers flexibility, high dielectric strength and conformability for easy handling and application. - In application, the tape maintains good electrical properties after elongation. Tape Super 10 is tough, conformable and resistant to solder damage. Its thermosetting rubber resin pressure sensitive adhesive has good initial adhesion and electrical purity.
Product Options
Showing 8 out of 21 options
 | Width: 4.25 Inch | EIS Part #: 3M10SUPX4.25 | $ / Roll Pack: 1/Roll | |
| Width: 3.5 Inch | EIS Part #: 3M10SUPX3.5 | $ / Roll Pack: 1/Roll | |
| Width: 3.062 Inch | EIS Part #: 3M10SUPX3.062 | $ / Roll | |
| Width: 2.5 Inch | EIS Part #: 3M10SUPX2.5 | $ / Roll | |
| Width: 2.25 Inch | EIS Part #: 3M10SUPX2.25 | $ / Roll | |
| Width: 2.125 Inch | EIS Part #: 3M10SUPX2.125 | $ / Roll | |
| Width: 2 Inch | EIS Part #: 3M10SUPX2 | $ / Roll | |
| Width: 1.875 Inch | EIS Part #: 3M10SUPX1.875 | $ / Roll |
- Attributes
- Features
- Applications
- Documents
Attributes
General Information
Item NameElectrical Tape
Trade Name3M
SeriesSuper 10
General Features
Shelf Life60 Months
Storage Temperature10 to 27 °C
Design & Construction
Adhesive TypeThermosetting Rubber
Backing MaterialEpoxy Film
ColorCream
Performance Details
Adhesive Strength45 oz/Inch
Breaking Strength45 lb/Inch
Flame RetardantYes
Tensile Strength45 lb/Inch
Electrical Properties
Dielectric Strength8000 V
Physical Properties
Core Size3 Inch
Elongation120%
Width-
Length60 Yard
Thickness5 Mil
Environmental Condition
ResistsHeat, Oxidation, Solvent, Oil
Temperature Rating155 °C
Features
- Tape is tough, conformable and resistant to solder damage
- Its thermosetting rubber adhesive has good initial adhesion and electrical purity
- Use as coil cover, anchor, harnessing, banding and as core, layer and crossover insulation
- Thicker, double-sided epoxy for higher temperature and dielectric
- The adhesive coating shall be smooth and uniform and be free of lumps and bare spots
- There shall be no separator between adjacent layers of the roll
- The tape shall perform at a temperature of 311 °F without loss of physical or electrical properties
- Temperature rating of 0 to 155 °C
Applications
- For Wrapping Relays, Coils, Transformers, Bobbin-Wound Sub-Fractional Horsepower Shaded-Pole Motors and Stick-Wound Coils, also for Holding in Fractional Horsepower Motors, Arbor-Wound Coils and Wire Harnesses
