MFR #:79
EIS #:PH22-79
MFR #:79
EIS #:PH22-79
3M glass cloth electrical tape 79 is a 7 Mil woven insulating glass cloth tape with an acrylic pressure sensitive adhesive. This tape is used to electrically insulate and provide mechanical protection at temperatures to 302 °F. It also features a superb absorption of resin and varnishes. - This tape provides insulation and solvent-resistant protection for use as coil cover, anchor, banding and core, layer and crossover insulation. It is edge tear resistant, conformable and printable.
$7.02
- $225.62
Select from the options below
3M glass cloth electrical tape 79 is a 7 Mil woven insulating glass cloth tape with an acrylic pressure sensitive adhesive. This tape is used to electrically insulate and provide mechanical protection at temperatures to 302 °F. It also features a superb absorption of resin and varnishes. - This tape provides insulation and solvent-resistant protection for use as coil cover, anchor, banding and core, layer and crossover insulation. It is edge tear resistant, conformable and printable.
Product Options
Showing 8 out of 18 options
Width: 4 Inch | EIS Part #: 3M79X4 | $ / Roll | ||
Width: 2.75 Inch | EIS Part #: 3M79X2.75 | $ / Roll | ||
Width: 2.31 Inch | EIS Part #: 3M79X2.31 | $ / Roll | ||
Width: 2 Inch | EIS Part #: 3M79X2 | $ / Roll | ||
Width: 1.625 Inch | EIS Part #: 3M79X1.625 | $ / Roll | ||
Width: 1.5 Inch | EIS Part #: 3M79X1.5 | $ / Roll | ||
Width: 1.25 Inch | EIS Part #: 3M79X1.25 | $ / Roll | ||
Width: 1.1875 Inch | EIS Part #: 3M79X1.187 | $ / Roll |
- Attributes
- Features
- Applications
- Documents
Attributes
General Information
Item NameElectrical Tape
Trade Name3M
Series79
General Features
Shelf Life60 Months
TypePaper Core
Design & Construction
Adhesive TypeAcrylic
Backing MaterialGlass Cloth
ColorWhite
Performance Details
Adhesive Strength30 oz/Inch
Breaking Strength150 lb/Inch
Flame RetardantNo
Tensile Strength150 psi
Electrical Properties
Dielectric Strength3000 V
Physical Properties
Core Size3 Inch
Elongation5%
Length60 Yard
Thickness7 Mil
Width-
Environmental Condition
ResistsSolvent, Tear
Temperature Rating32 °F
Features
- Woven insulating glass cloth tape featuring an acrylic, pressure sensitive adhesive
- Electrically insulates and provides mechanical protection at temperatures to 150 °F
- Edge tear resistant and conformable
- Temperature rating of 32 to 302 °F
Applications
- For Bobbin Wound Coils, Banding Arbor Wound Coils, Lead Pad Hold Down, End Turn and Lead Anchor and Connection
