MFR #:6211 ZJEM
EIS #:6211Z04
Series #:6211
UPC #:07316576681370
MFR #:6211 ZJEM
EIS #:6211Z04
Series #:6211
UPC #:07316576681370
Low Stock
Min Qty:1
|Qty Increment:1
SKF 6200 single row deep groove ball bearings have deep, uninterrupted raceway grooves. These raceway grooves have a close osculation with the balls, enabling the bearings to accommodate radial loads and axial loads in both directions. Single row deep groove ball bearings are available open or capped (with seals or shields). Open bearings that are also available capped, may have recesses in the outer ring. - SKF 6200 single row deep groove radial ball bearings have deep, uninterrupted raceway grooves. These raceway grooves have a close osculation with the balls, enabling the bearings to accommodate radial loads and axial loads in both directions.
$88.89 / Piece
Min Qty:1
|Qty Increment:1
SKF 6200 single row deep groove ball bearings have deep, uninterrupted raceway grooves. These raceway grooves have a close osculation with the balls, enabling the bearings to accommodate radial loads and axial loads in both directions. Single row deep groove ball bearings are available open or capped (with seals or shields). Open bearings that are also available capped, may have recesses in the outer ring. - SKF 6200 single row deep groove radial ball bearings have deep, uninterrupted raceway grooves. These raceway grooves have a close osculation with the balls, enabling the bearings to accommodate radial loads and axial loads in both directions.
- Attributes
- Features
- Applications
Attributes
General Information
Item NameDeep Groove Radial Ball Bearing
Series6211
General Features
Net Weight0.621kg
Design & Construction
Cage MaterialPressed Steel
Enclosure TypeSingle Shield
Performance Details
Dynamic Load Capacity46200 N
Static Load Capacity29000 N
Tolerance ClassP6, P5
Physical Properties
Bore Diameter55 mm
Fillet Radius1.5 mm
Number of Rows1
Outside Diameter100 mm
Width21 mm
Features
- Comes with improved dimensions
- Generates 50% less noise
- Operational cost and maintenance are low
- Clearance: C3
- Speed Rating: 9000 rpm Limiting, 14000 rpm Reference
- Temperature Rating: -40 to 100 °C
Applications
- Can be Used In Fans, Pumps, Agriculture, Etc
