The image shown is representative of the product family and may not specifically be the individual item.  6219ZC3 - Deep Groove Ball Bearing, Deep Groove Ball Bearings
JTEKT/KOYO

JTEKT Bearings 6203ZZC3 - Double Shield, 17 mm ID, 40 mm OD, 12 mm Width,, C3 Internal Clearance, MFR ID KOY-6203ZZC3GXM

  • MFR #6203ZZC3
  • EIS #6203ZZC308
  • UPC #605790058042
  • Midpoint #KOY-6203ZZC3GXM
$4.07 / Piece
In Stock | Ready to Ship
Min QTY1QTY Increment1
more info

6203ZZC3 - Deep Groove Ball Bearing, Deep Groove Ball Bearings

General Information

Item NameDeep Groove Ball Bearings

General Features

Net Weight0.147 lb

Design & Construction

Bore TypeRound
Cage MaterialSteel
Cage TypeRiveted
Closure Type2 Shields
Lubrication TypeGrease
MaterialSteel
Rolling ElementBall
Rolling Element MaterialHigh Carbon Chromium Bearing Steel
Row TypeSingle row

Performance Details

Dynamic Load Capacity12 kn
Operating Temperature-30 to 110 °C
Precision ClassClass 0
Self AligningNo
Speed Rating17000 rpm (Grease)
Static Load Capacity4.8 kn

Physical Properties

Bore Diameter17 mm
Fillet Radius0.0236 Inch
Outside Diameter40 mm
Overall Width12 mm
