3M 9172MP Double Linered Aluminum Foil Adhesive Transfer Tape, 24" x 60 yd x 2.3 Mil, Clear, 1/Case, MFR ID 7010372445
- EIS #3M9172MPX24
- UPC #00021200687952
Requires Quote / Roll
Available to Order
Min QTY1QTY Increment1
more info
Pack1/Case
Products You May Also Like
3M™ Adhesive Transfer Tape Double Linered 9172MP features 3M™ High Performance Acrylic Adhesive 200MP, the industry standard for graphic attachment and die-cut parts. It offers excellent shear strength, minimal edge lifting and reduced slippage on medium to high-surface energy plastics. A 2.0 mil clear HDPE liner makes for easy visual inspection, and a 58 lb. PCK liner adds dimensional stability. - This adhesive provides some initial repositionability for placement accuracy when bonding to plastics. It also performs well after exposure to humidity and hot/cold cycles.
Features
- Up to 400 °F short-term heat resistance
- Excellent solvent resistance
- Excellent shear strength to resist slippage and edge lifting
- Temperature rating of -40 to 400 °F
Applications
- For Graphic Attachment, General Industrial Joining, Bonding for Aerospace/Medical/Industrial Equipment/Automotive Appliance/Electronic Markets/Telecommunications, Lamination
General Information
| Item Name | Adhesive Transfer Tape |
| Trade Name | 3M |
| Series | 9172MP |
General Features
| Type | Double Linered |
| Shelf Life | 18 Months |
| Storage Temperature | 21 °C |
Design & Construction
| Adhesive Type | Acrylic |
| Backing Material | Aluminum Foil |
| Color | Clear |
Performance Details
| Adhesive Strength | 168 oz/Inch |
Physical Properties
| Core Size | 3 Inch |
| Width | 24 Inch |
| Length | 60 Yard |
| Thickness | 2.3 mil |
Environmental Condition
| Resists | Humidity, UV, Chemical, Water, Temperature, Heat |
| Temperature Rating | 400 °F |
