JTEKT Bearings 7220B-5DWGC3 - Single Row, Universal Ground, 40 Degree Contact Angle, Brass Cage, 100 mm ID, 180 mm OD, 34 mm Width,, C3 Internal Clearance

The image shown is representative of the product family and may not specifically be the individual item. 7220B-5DWGC3 -Angular Contact Bearing, Single Row

MFR #:7220B-5DWGC3FY

EIS #:7220B-5DWGC3;FY08

UPC #:605790361494

Midpoint #:KOY-7220B-5DWGC3FY

MFR #:7220B-5DWGC3FY

EIS #:7220B-5DWGC3;FY08

UPC #:605790361494

Midpoint #:KOY-7220B-5DWGC3FY

In Stock

Min Qty:1

  |

Qty Increment:1

JTEKT/KOYO
JTEKT/KOYO
7220B-5DWGC3 -Angular Contact Bearing, Single Row
$285.66 / Piece

Min Qty:1

  |

Qty Increment:1

JTEKT/KOYO
JTEKT/KOYO
7220B-5DWGC3 -Angular Contact Bearing, Single Row

Attributes

General Information
Item NameAngular Contact Bearings
Series7200
General Features
Net Weight8.36 lb
Design & Construction
Bore TypeCylindrical
Cage MaterialBrass
Cage TypeMachined
Lubrication TypeRust Preventative
Material52100
Mounting TypeSingle
Retainer MaterialBrass
Retainer TypeMachined
Rolling ElementBall
Rolling Element MaterialBall
Row TypeSingle row
Performance Details
Contact Angle40°
Dynamic Load Capacity155 kn
Operating Temperature-54 to 121 °C
Precision ClassClass 0
Self AligningNo
Speed Rating3100 rpm (Grease) | 4200 rpm (Oil)
Static Load Capacity107 kn
Physical Properties
Bore Diameter100 mm
Fillet Radius0.0787 Inch
Number of Bearings1
Outside Diameter180 mm
Overall Width34 mm
Radial Internal ClearanceC3
